Series Introduction

Welcome to the next evolution of the "Meet Me In..." research series. The goal of the series has always been to educate, create awareness, and highlight key facts about where, how and why the physical networks that make up the world's information infrastructure meet.

Read More +

Then

The original research series featured both San Francisco and separately Santa Clara, California. In hindsight, the entire Bay Area is a network interconnection zone, but back then things were still very much telco verses web hosting. Knowing where core, long-haul fiber transport networks were located in a neutral site for easy, direct access was generally more important than knowing where the websites themselves were located. For that reason, 200 Paul Ave in San Francisco was the main carrier hotel and neutral interconnection facility for the city at the time. Santa Clara was and is considered more of a hosting facility, now known as data center, area, but the 1100 Space Park property was of particular interest because of the TYCO Trans-Pacific Subsea system that was located there. This made it more than just a hosting facility / data center and thus was featured in the Meet Me In series.

Read the original 2003 (San Francisco) article

Read the original 2004 (Santa Clara) article

Read the original 2005 (San Francisco) article

Now

With the help of a favorable mix of population density, proximity, existing Right of Way infrastructure, Internet protocol demand and growth and the resulting metro dark fiber investment to connect it all, this particular market has morphed in to a network interconnection super-region. As a result, it would not make sense to narrowly focus on only one city by name. Given the Internet Exchange (IX) focus on the current 2022 research, the search area has been expanded to encompass a much larger geographic area. Therefore, the results tell a different story than in a traditional city with a single dominant carrier hotel remaining dominant for almost two decades.


San Francisco (Bay Area) Internet Exchanges

With the inclusion of Fremont, Palo Alto and San Jose the research shows Any2West currently being the dominant IX with 286 ASN’s available in 6 sites and Equinix just behind with 222 ASN’s available in 4 sites, but interestingly, the Hurricane Electric facility at 48233 Warm Springs Blvd has an aggregate of 710 ASN’s across 11 IX’s accessible from the facility. The research does not account for overlap in ASN’s on multiple IX’s, so there could be some duplication of value in the whole number, but it is still worth noting that this facility has that many options.

The Top 5 Networks (all on the Any2West and the Equinix Sam Jose IX) by number of IX’s connected to, are, Hurricane Electric, CloudFlare, Google, Yahoo!, and Microsoft.

The tables below display live data on all IXs in the region highlighted in this map image.
Map of the search area

San Francisco (Bay Area) - Internet Exchanges by Location Address

Address IX`s @ Facilities @ IX Name: Any2West Equinix San Jose EVIX LL-IX FCIX NetIX Equinix Palo Alto SFMIX Lambda-IX AMS-IX BA BGP.Exchange ARIX Pacific Wave FREMIX Skywolf IX US EO-IX Global Peer Exchange NASA-AIX Ninja-IX Bay Area
      #ASNs: 286 222 218 150 129 116 102 87 29 26 25 17 13 13 8 8 4 2 0
48233 Warm Springs Blvd 11
529 Bryant St 4
55 S. Market Street 2
200 Paul Ave 2
255 Caspian Dr 2
365 Main Street 2
444 Toyama Dr 2
760 Mission Ct 2
1350 Duane Ave 2
1735 Lundy Ave 2
2972 Stender Way 2
Building N254 1
1380 Kifer Rd. 1
1656 McCarthy Blvd. 1
1700 Richard Avenue 1
2807 Mission College Blvd 1
2901 Stender Way 1
3020 Coronado Drive 1
3045 Stender Way 1
Address IX`s @ Facilities @ IX Name: Any2West Equinix San Jose EVIX LL-IX FCIX NetIX Equinix Palo Alto SFMIX Lambda-IX AMS-IX BA BGP.Exchange ARIX Pacific Wave FREMIX Skywolf IX US EO-IX Global Peer Exchange NASA-AIX Ninja-IX Bay Area
      #ASNs: 286 222 218 150 129 116 102 87 29 26 25 17 13 13 8 8 4 2 0
48233 Warm Springs Blvd 11
529 Bryant St 4
55 S. Market Street 2
200 Paul Ave 2
255 Caspian Dr 2
365 Main Street 2
444 Toyama Dr 2
760 Mission Ct 2
1350 Duane Ave 2
1735 Lundy Ave 2
2972 Stender Way 2
Building N254 1
1380 Kifer Rd. 1
1656 McCarthy Blvd. 1
1700 Richard Avenue 1
2807 Mission College Blvd 1
2901 Stender Way 1
3020 Coronado Drive 1
3045 Stender Way 1

All data is courtesy of peeringdb.com. Live data is refreshed nightly. If you see innacurate data for your organization, or your organizaion is missing, please update or create your profile at peeringdb.com and allow 24 hours for this table to update.


San Francisco (Bay Area) - Networks by Internet Exchange

Network Name (ASN) #IX`s IX Name: Any2West Equinix San Jose EVIX LL-IX FCIX NetIX Equinix Palo Alto SFMIX Lambda-IX AMS-IX BA BGP.Exchange ARIX Pacific Wave FREMIX Skywolf IX US EO-IX Global Peer Exchange NASA-AIX Ninja-IX Bay Area
    #ASNs: 286 222 218 150 129 116 102 87 29 26 25 17 13 13 8 8 4 2 0
Hurricane Electric (6939) 9
Google LLC (15169) 7
Cloudflare (13335) 7
Yahoo! (10310) 6
Microsoft (8075) 6
PCH AS42 (42) 6
Akamai Technologies (20940) 5
PCH AS3856 (3856) 5
Amazon.com (16509) 5
Blizzard Entertainment (57976) 5
FogNet - iFog GmbH (34927) 5
Edgio - AS22822 (22822) 4
Webpass (19165) 4
Internap (29791) 4
AARNet (7575) 4
Meta (32934) 4
Salesforce.com (14340) 4
OVHcloud (16276) 4
Wave Division Holdings (11404) 4
Edgio (Edgecast) - AS15133 (15133) 4
i3D.net (49544) 4
G-Core Labs (199524) 4
DigitalOcean (14061) 4
Netskope (55256) 4
Subspace (32261) 4
RITSNET (17117) 4
BSO (4455) 4
Arpan Sen (142598) 4
Low End Network (210872) 4
ZH Innovation Network (210320) 4
DAOport Infrastructures (210000) 4
Colt (8220) 3
Two P (6140) 3
Netflix (2906) 3
365 Data Centers (BroadbandONE) (19151) 3
Akamai Prolexic DDoS Mitigation (32787) 3
LeaseWeb Network (16265) 3
Etisalat (8966) 3
M-ROOT DNS Server (7500) 3
Unwired (32354) 3
Internet2 I2PX (11164) 3
IPTP Networks (41095) 3
Wikimedia Foundation (14907) 3
Telstra (International) (4637) 3
SoftLayer Technologies, Inc. (an IBM Company) (36351) 3
Race Telecommunications (30041) 3
DREN (668) 3
Weebly (27647) 3
Telekomunikasi Indonesia Int (TELIN) (7713) 3
InfoWest (11071) 3
Netnod (8674) 3
Joe's Datacenter (19969) 3
Twitter, Inc. (13414) 3
Apple Inc. (714) 3
NetActuate (36236) 3
Tencent Global (132203) 3
Fastly, Inc. (54113) 3
Riot Games (6507) 3
Softcom Internet Communications (13427) 3
TripleT Broadband(3BB) (45758) 3
ISC F-ROOT OAK1 (27321) 3
ROBLOX (22697) 3
Sail Internet (396097) 3
Ridge Wireless (33452) 3
Unwired Broadband (33548) 3
Optix Transit Ltd (209870) 3
Securebit AG (58057) 3
Airgapped (6556) 3
10VPN Research Network (49134) 3
ipFail Networks (62538) 3
Tiny Tiny Computing (398419) 3
ANSIBLE Networks (14570) 3
Ohanacraft (398447) 3
TOHUNET (140731) 3
Jimmy Pan (212360) 3
fixmix Global Network (211876) 3
Baoshuo Network (141776) 3
PWTSAI Network (211622) 3
Martin Gotlund (211168) 3
Air's Project Private Network (142553) 3
Okita Online (147028) 3
DigitalMonks LLC (400006) 3
Cloudie Networks AS924 (924) 3
VNP (56328) 3
Renesys (34135) 2
KT Corporation (Korea Telecom) (4766) 2
Global Cloud Xchange (15412) 2
Orange Business Services North America (2647) 2
Vodafone Global Network (1273) 2
China Telecom (4134) 2
Shaw Cablesystems (6327) 2
CENIC / CalREN AS2152 (2152) 2
TDC A/S (3292) 2
Frontier Communications of America (FCA) (5650) 2
Exponential Interactive, Inc. (33419) 2
Docomo Pacific (3605) 2
M247 (9009) 2
Internet Initiative Japan (2497) 2
TWGate (9505) 2
Cisco Umbrella (36692) 2
Singapore Telecommunications Limited (7473) 2
CacheFly (30081) 2
Los Nettos (226) 2
Fiber Internet Center (26803) 2
Energy Sciences Network (ESnet) (293) 2
NTT Global IP Network (2914) 2
Zenlayer Inc (21859) 2
Fireline Network Solutions, Inc dba: Fireline Broadband (40511) 2
WebEx Communications (13445) 2
GTA/Teleguam Holdings, LLC (9246) 2
Community Network Center Inc. (CNCI) (9354) 2
Vocus Communications (4826) 2
Forcepoint Cloud (44444) 2
Windstream Communications (7029) 2
Hong Kong Broadband Network LTD (9269) 2
Matrix Cable International Exchange (MCIX) (55818) 2
Bharti Airtel (9498) 2
Box (33011) 2
Amazon IVS / Twitch (46489) 2
ARTERIA Networks Corporation (Vectant) (2519) 2
Taiwan Fixed Network (9924) 2
BIGLOBE Inc. (2518) 2
TPG Telecom (7545) 2
6connect (8038) 2
Flō Networks (32098) 2
CityLink Telecommunications NM, LLC (7850) 2
OPTAGE (17511) 2
Nexusguard (45474) 2
Qualcomm Inc (11030) 2
Square AS15211 (15211) 2
Saudi Telecom Company (STC IGW) (39386) 2
GigaMonster (31939) 2
OneCom Global Communications (51185) 2
Wholesale Internet, Inc. (32097) 2
intibu (48292) 2
Sony Interactive Entertainment (PlayStation) (33353) 2
RouteViews (6447) 2
Dropbox (19679) 2
T-Mobile USA (21928) 2
SG.GS (24482) 2
Equinix Internet Exchange - MLPE (24115) 2
Convergenze S.p.A. (39120) 2
VOXILITY (3223) 2
Zscaler AS22616 (22616) 2
Unitas Global (1828) 2
China Mobile International (58453) 2
TelePacific Communications (14265) 2
Syringa Networks (15305) 2
WIZ (54415) 2
Valve Corporation (32590) 2
RingCentral (40627) 2
Zeta Global Corp. (54312) 2
Index Exchange (27381) 2
Anycast Global Backbone (58511) 2
Superloop (38195) 2
PubMatic (62713) 2
